5PCS Type-C Female Chassis 2 Pin Type-C Female Socket Connector Waterproof Jack Charging Port with Card Buckle 3A USB-C Charger Plug Socket
4.9 (82 items)
Limited Time Sale$3.59 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 237364537 | Release Date | 2026/07/10 | List Price | $2.39 | Model Number | 237364537 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
【Materials:】 Forming: LCP UL94 V-0 Contacts: minimum copper alloy gold plating on the contact area, minimum tin plating on the soldering area 100uMin (lead-free) Shell: SUS304-H, T=0.30±0.03mm50u” full nickel-plated 【Machinery】 Insertion: 5~20N Extraction: 820N Test Durability: 10000 【Electrical】 Current: 3A for VBUS; 1.25A for GND PIN0.25A for others Voltage: 20V Maximum withstand voltage: 100V AC R.M.S Contact resistance: 40mq Maximum insulation resistance: 100MQ Temperature range: -25℃ +85℃ Package include: 5 x USB Type C Connector
- Made of environmentally friendly PVC material, the interface is tightly connected, which is not easy to be disconnected.
- Type-C pigtail bare wire is Type-C female head, and one end is 2-pin 2-wire bare wire, providing a safe and simple DIY solution for type-C connector with cable.
- Usb-C Electronic Cable, red positive electrode, black negative electrode, easy to operate, rated voltage: 5V, maximum current: 3A.
- The tail of the type-C female chassis cable has been reserved for stripping to facilitate welding installation and connection.
- Widely used in the automotive industry, smart products, household appliances, medical equipment, communication equipment, etc.
| UPC | 687117705150 |
|---|---|
| ASIN | B0C88S67Q7 |
| Brand | ALMOCN |
| Color | Black |
| Finish | Metallic |
| Manufacturer | ALMOCN |
| Model Number | ALMOCN-unknown |
| Input Voltage | 5 Volts |
| Nominal Power | 15 Watts |
| Connector Type | USB Type C |
| Current Rating | 3 Amps |
| Number of Items | 4 |
| Number of Ports | 1 |
| Power Plug Type | No Plug |
| Package Quantity | 1 |
| Compatible Devices | Laptop |
| Smart Home Compatibility | Not Smart Home Compatible |
